Description
Overview
The Omega Diamond Blue Ripper Jr is a portable rail-guided stone saw for shop and on-site cutting. The 19.8 lb. machine uses an 8" blade and a 120V power cord with GFCI, with either a saw-only configuration or the selected package with 7' and 12' rails.
Features
- Portable 19.8 lb. saw platform.
- Up to approximately 4 cm cutting depth with the specified blade setup.
- 45° miter capability with the separate compatible Miter Base.
- Saw-only and rail-package choices.
What's Included
- Blue Ripper Jr rail saw in the selected configuration
- 7' and 12' rails only when the saw-with-rails option is selected
Specifications
- Model: 948-421
- Blade size: 8"
- Listed speed: 4,500 RPM
- Cutting depth: Approximately 1.5" / 4 cm
- Power: 120V cord with GFCI
- Weight: 19.8 lb.
- Manufacturer cutting example: 4 ft./minute on 2 cm Absolute Black granite; step cutting recommended
Type Options
- Saw Only
- Saw with 7' & 12' Rail
Applications
Use for rail-guided cuts in granite, marble and other compatible stone with the appropriate blade. The 4 ft./minute example is tied to a specific granite thickness, not a guaranteed rate for every material. A compatible Miter Base is required for the stated 45° miter function.
Selection and Use
- Saw Only does not include guide rails; choose the rail-package option if those rails are needed.
- Match blade type to the stone and follow the prescribed water, power and cutting procedure. Use step cutting as recommended for the job.
- Check machine compatibility before adding a Miter Base; straight-cut capacity should not be assumed to be the miter capacity.
