Description
Overview
The Makita XCV10PTX is a 1/2-gallon backpack dry dust-extractor kit powered by two 18V LXT batteries. Its brushless motor supplies 64 CFM and 44 in. of water lift, with a padded harness and belt-mounted controller for cordless cleanup and tool-connected extraction.
Features
- Powerful brushless motor generates 64 CFM suction and 44" water lift
- Up to 62 minutes of continuous runtime on low, 33 minutes on high with two 18V 5.0Ah batteries
- Efficient 2-stage HEPA filter captures 99.97% of particulates .3 microns and larger
- Auto-start Wireless System (AWS) for wireless on/off communication with tools (transmitter sold separately)
- Includes 3 tool adapters for hose connection to Makita dust extraction attachments
- Push button controller for power (high/normal) and AWS, attaches to harness waist belt
- Lightweight, compact design; weighs only 10 lbs. with batteries
- Quiet operation: 69 dB(A) on high, 65 dB(A) on normal
- Padded adjustable shoulder straps and waist belt for comfort
- Extreme Protection Technology (XPT) for improved dust and water resistance
- Equipped with Star Protection Computer Controls™ to prevent overload, over-discharge, and overheating
- 3-year limited warranty on tool, batteries, and charger
What's Included
- (1) 36V (18V X2) LXT Brushless 1/2 Gal. HEPA Filter Backpack Dust Extractor, AWS Capable (XCV10ZX)
- (2) 18V LXT Lithium-Ion 5.0Ah Batteries (BL1850B)
- (1) 18V LXT Dual Port Rapid Optimum Charger (DC18RD)
- (1) Flexible Hose, 1" x 59" (152992-0)
- (1) HEPA Filter (127725-2)
- (1) Tool Cuff Adapter, 22mm for 1" hose (417765-1)
- (1) Tool Cuff Adapter, 24mm for 1" hose (424379-9)
- (1) Tool Cuff Adapter, 38mm for 1" hose (417766-9)
- (1) Harness (162469-7)
- (1) Filter Dust Bag
Specifications
- Capacity: 0.5 gal.
- Air Flow Rate: 64 CFM
- Static Water Lift: 44"
- HEPA Filter: Yes (99.97% efficiency at .3 microns)
- Runtime (two 5.0Ah batteries): Up to 62 min low/normal; 33 min high
- Noise Level: 65–69 dB(A)
- Net Weight (with batteries): 10 lbs.
- Battery: 2X 18V LXT Lithium-Ion
- Motor Type: Brushless
Downloads
Applications
For dry cleanup and construction dust extraction as part of a compatible tool-and-extractor setup. The three supplied hose adapters connect to suitable Makita dust-extraction attachments; confirm the connection required by the tool.
Selection and Use
- AWS wireless tool-triggered operation requires the 198901-5 transmitter, sold separately.
- Runtime is up to 62 minutes on low/normal or 33 minutes on high using two 5.0Ah BL1850B batteries.
- The 10 lb. operating weight is with an empty dust bag and two 5.0Ah batteries.
- This is a dry extractor, not a wet-pickup vacuum.
