Laticrete

Laticrete Hydro Ban Pre-Sloped Shower Pan

12 reviews Write a Review
SKU:
70.54000
MPN:
9353-3648-ABS
$581.95
Laticrete Hydro Ban Pre-Sloped Shower Pan
Ask a question View Q&A
  • Fast, Reliable Shipping
  • Expert Product Support
  • 30+ Years of Experience.
Laticrete Hydro Ban Pre-Sloped Shower Pan

Description

Overview

The HYDRO BAN Pre-Sloped Shower Pan is a lightweight, factory-waterproofed base for tiled showers. It replaces a site-built mortar base within its footprint and comes with curb material and adhesive/sealant. Choose both the pan dimensions/drain layout and the PVC or ABS connection to match the project.

Features

  • Pre-sloped, ready-to-tile construction.
  • Can be modified on site following the manufacturerā€™s instructions.
  • Factory waterproofing meets ANSI A118.10; assembly meets IAPMO-PS-46.
  • Eligible assemblies may qualify for the LATICRETE Lifetime System Warranty, subject to its terms.

What's Included

  • Selected HYDRO BAN Pre-Sloped Shower Pan.
  • HYDRO BAN preformed curb.
  • One tube of HYDRO BAN Adhesive & Sealant.
  • Drain grate not included.

Specifications

  • Center-drain sizes: 36 x 48, 36 x 60, 48 x 48 and 48 x 60 in.
  • Off-center size: 38 x 66 in.
  • Connection options: PVC or ABS
  • Size: 36" x 48"; 36" x 60"; 48" x 48"; 48" x 60"; 38" x 66" Off Center Drain
  • Type: ABS; PVC

Downloads

Applications

Use to form the base of a tiled shower with a coordinated HYDRO BAN waterproofing assembly. Pan footprint, waste position, curb location and drain-grate selection must be planned together.

Plan Your Installation

  • Measure the opening and waste location before choosing Size and Type; a matching footprint alone does not establish drain alignment.
  • Dry-fit and modify only as permitted by the pan instructions, then complete the wall, curb and pan transitions.
  • Order the compatible drain grate separately. Do not assume the grate shown in a system image is included.

Common Planning Questions

Is this just a bare pan?

No. The listed package includes the selected pan, preformed curb and one tube of HYDRO BAN Adhesive & Sealant.

Is the drain grate included?

No. Drain grates are sold separately.

Extra Information

Brand:
Laticrete
70.54000:
9353-3648-ABS
70.54100:
9352-3648-PVC
70.53800:
9351-3660-ABS
70.53900:
9350-3660-PVC
70.53600:
9363-4848-ABS
70.53700:
9362-4848-PVC
70.54200:
9361-4860-ABS
70.54300:
9360-4860-PVC
70.54400:
9371-3866-ABS
70.54500:
9370-3866-PVC
Dropship Field:
ADDITIONAL 1-2 DAYS FOR ORDER PROCESSING

    12 Reviews

  • Posted by Tim Fox on Sep 25, 2024

    5

    Laticrete Pre-Sloped Shower Pan

    The item came in on time with do damage to the product. Ordering was quick and easy, with a few different shipping options. The item was priced extremely competitively. Great experience overall.

  • Posted by Nicholas Borsellino on Jan 26, 2024

    4

    HydroBan Off Center Shower Pan

    We had to cut 3 inches off the sides and one inch off the front and 5 off the back. Did it all on a table saw, with two people. Remade the rabbet joints on the table saw and everything. Only issue was we were stepping on it while installing the durock and the overhead light and the styrofoam had dimples all over it from out feet. Easy to solve, we just skim coated it with the Laticrete MultiMax thin set that we used when installing the bench seat. Then tiles went in perfectly. It actually helped greatly even out the surface because we were using small detail sheet tiles.

  • Posted by John Kreamer on Dec 27, 2023

    5

    Hydro Ban Pre-Sloped Shower Pan

    I used to use the "Kerdi" system for showers, but switched to Hydro Ban four years ago. I will never go back! Excellent system--no call backs--no problems.

  • Posted by Derek on Sep 23, 2023

    4

    great pan at a great price

    Looking forward to setting thr pan. All the product videos make it look really seamless. Very lightweight easy to handle. The only thing that could have been better was the packaging. Althogh some scuffs in the pans surface are easily filled/sealed, my pan was pretty beat up by the time it got to me. The sealant/adhesive tube and drain hardware box bounced around quite a bit, dinging the corners up pretty good. Even though everything gets covered up eventually, it would have been better to see the factory-waterproofing and corners in better shape from day one.

  • Posted by Justice Henecke on Sep 6, 2022

    4

    Fast shipping, easy to use web site

    Had no problems using the website. Product shipped within a week with no damage.

  • Posted by Caris Mason on Jan 26, 2022

    3

    Shower Pan

    Shipping process didn't provide notification initially. I had to call to obtain the status.

  • Posted by Bob Frick on Nov 25, 2021

    5

    Service after the sale has been excellent

    The 60 by 36 pan came damaged during transit. Though salvageable with modification that is not the point in purchasing a hydro ban shower pan. After calling and describing issue they promptly reshipped and sent ups to pick up damaged pan

  • Posted by Dan Maguire on Oct 6, 2021

    5

    Shower Pan

    Had to cut down to 56" was surprised how easy it was to get the perfect fit

  • Posted by Cameron Bates on Apr 26, 2021

    5

    Such a time saver!

    The product was shipped standing upright on its own pallet to avoid any damage during shipping. I've never seen a product shipped like that! And the base is sturdy and easy to trim to get an exact fit in your space. Very happy with this purchase.
