Description
Overview
The Sink Hole Saver Edge V3 reinforces fragile stone by mechanically gripping the edges rather than attaching vacuum cups to the face. Sliding clamps position along the stiffening rail, with improved tightening knobs and rubber bumper guards at finished edges.
Features
- Mechanical clamps adjust along the rail.
- 18ā53 mm clamping range.
- 4 ft, 6 ft and 8 ft nominal size choices.
What's Included
- One rail in the selected size
- Mechanical clamps
Specifications
Size Options
- 4' Sink Hole Saver Edge 4101-SHSE-17
- 6' Sink Hole Saver Edge 6101-SHSE-17
- 8' Sink Hole Saver Edge 8101-SHSE-17
4101-SHSE-17
- Model #: 4101-SHSE-17
- Product Dimensions: 48" x 3.5" x 6"
- Clamping Range: 18 mm to 53 mm (0.7 in. to 2.1 in.)
- Product Weight: 6.9 lb
6101-SHSE-17
- Model #: 6101-SHSE-17
- Product Dimensions: 72" x 3.5" x 6"
- Clamping Range: 18 mm to 53 mm (0.7 in. to 2.1 in.)
- Product Weight: 9.9 lb
8101-SHSE-17
- Model #: 8101-SHSE-17
- Product Dimensions: 95" x 3.5" x 6"
- Clamping Range: 18 mm to 53 mm (0.7 in. to 2.1 in.)
- Product Weight: 11.9 lb
Downloads
Applications
Use for reinforcing cutout areas, backsplashes and other fragile stone sections during fabrication, transport and installation.
Selection and Use
- Choose a rail long enough to reinforce the vulnerable area; the nominal 8 ft model is listed at 95 in. overall.
- Verify that the edge thickness is within 18ā53 mm and the clamps can be positioned without interfering with the work.
- Use the linked product guide for assembly and handling requirements.
