Description
Overview
The Hawk BRUTE 17 in. floor machine is built for demanding surface-preparation and restoration work. Its 1.5 HP, 180-frame TEFC motor drives through an 11:1 triple-planetary gear system at 165 RPM, with an all-steel welded frame for shop and jobsite use.
Features
- For concrete resurfacing, natural-stone polishing, wood screening and sanding with suitable tooling.
- Dual operating triggers, thumb-operated safety switch and adjustable handle.
- Industrial helical-cut drive gears.
- Two 25 lb weights included in this listed package.
What's Included
- Hawk BRUTE 17 in. floor machine.
- Two 25 lb weights.
Specifications
- Listed machine model: HP1517-180 TE
- Catalog assembly: F37-01-B + AO300-2
- Machine size: 17 in.
- Motor: 1.5 HP; 180-frame TEFC, dual capacitor
- Pad speed: 165 RPM
- Power: 115–230 V, 60 Hz
- Cord: 50 ft. industrial cord with cord lock
- Drive: Triple-planetary XHD 11:1 helical-cut gears
- Listed machine weight: 123 lb; do not assume this includes the two accessory weights
- Sound level: 66 dB average; manufacturer identifies GS42 compliance
- Listing: UL/CUL listed
Downloads
Applications
Use for compatible floor restoration and preparation in commercial, industrial or residential work. The machine supplies rotary power; the selected brush, pad or abrasive determines whether you are resurfacing concrete, polishing stone, screening wood or sanding.
Selection and Use
- Match tooling to both the task and the 165 RPM drive.
- Check electrical supply and machine configuration before operation.
- Use the added weights only within the limits of the machine and attached tool. Some coating-removal tools have lower machine-weight limits.
- Review the existing manual for handling, startup and maintenance before use.
