Description
Overview
The Abaco Little Giant ALG-series Slab Lifter grips stone slabs with rubber-padded clamp plates and works with a hoist or forklift lifting arrangement. Five selectable models cover different slab-thickness ranges; the largest model is not automatically the correct choice for a thinner slab.
Features
- Aluminum main construction balances strength and handling weight.
- Rubber clamp pads provide friction and cushion slab contact.
- An included swivel shackle permits 360-degree rotation for positioning.
What's Included
- Selected ALG lifter with rubber-padded clamp plates.
- Swivel shackle.
Specifications
Color Options
- Black Rubber
- White Rubber
Size Options
- ALG30
- ALG40
- ALG50
- ALG60
- ALG75
ALG30
- Length (inches / mm): 7-7/8" (200)
- Width (inches / mm): 5-11/16" (144)
- Height (inches / mm): 12-13/16" (326)
- Grip Range (inches / mm): 3/8" - 1-3/16" (10~30)
- Net Weight: 34.1 lbs
- Work Load Limit: 2,200 lbs
ALG40
- Length (inches / mm): 8-5/16" (211)
- Width (inches / mm): 6-13/16" (173)
- Height (inches / mm): 14-9/16" (370)
- Grip Range (inches / mm): 3/8" - 1-9/16" (10~40)
- Net Weight: 49.5 lbs
- Work Load Limit: 2,860 lbs
ALG50
- Length (inches / mm): 8-5/16" (211)
- Width (inches / mm): 7-3/16" (183)
- Height (inches / mm): 14-9/16" (370)
- Grip Range (inches / mm): 3/8" - 1-15/16" (10~50)
- Net Weight: 50.6 lbs
- Work Load Limit: 2,860 lbs
ALG60
- Length (inches / mm): 8-1/2" (216)
- Width (inches / mm): 7-15/16" (202)
- Height (inches / mm): 15-7/8" (403)
- Grip Range (inches / mm): 13/16" - 2-3/8" (20~60)
- Net Weight: 61.6 lbs
- Work Load Limit: 3,300 lbs
ALG75
- Length (inches / mm): 8-1/2" (216)
- Width (inches / mm): 8-7/16" (214)
- Height (inches / mm): 15-7/8" (403)
- Grip Range (inches / mm): 1-3/16" - 2-15/16" (30~75)
- Net Weight: 61.6 lbs
- Work Load Limit: 3,300 lbs
Applications
Use the ALG-series for lifting natural or artificial stone slabs and compatible flat materials in workshops, warehouses and construction handling areas.
Selection and Use
- Match both ends of the grip range: ALG30/40/50 start at 10 mm, ALG60 at 20 mm, and ALG75 at 30 mm.
- Work load limits differ by model: ALG30 is 2,200 lb; ALG40/50 are 2,860 lb; ALG60/75 are 3,300 lb.
- Select black or white rubber as offered, and match the hoist or forklift lifting arrangement to the selected lifter and load.
