Description
Overview
The STABILA LAX 50 G kit projects a green horizontal and vertical cross line for interior alignment. Its magnetic multi-purpose mount and 58–120 in. telescopic support let you set the reference at a useful working height.
Features
- Self-leveling pendulum with ±4.5° range.
- Rotating platform with 1/4 in. and 5/8 in. tripod connections.
- Rare-earth magnetic attachment, wall hanging hole and pipe/conduit clamp up to 1-1/8 in. diameter.
What's Included
- LAX 50 G laser
- Magnetic multi-purpose mount
- 58–120 in. telescopic mount
- 3 AA batteries
- Carry pouch
- Owner’s manual
Specifications
- Catalog number: 03265GP
- Kit: 03265GP
- Visible line range: Up to 100 ft (30 m)
- Leveling accuracy: 0.5 mm/m; approximately 3/16 in. at 30 ft
- Laser: Class 2; under 1 mW; 510–530 nm
- Runtime: Approximately 7 hours
- Power: 3 AA batteries
- Protection: IP53
- Telescopic support: 58–120 in. openings
Applications
Use for kitchen cabinets and countertops, tile layout, switches and cable ducts, pipe clips, or decorating reference lines. The pole and magnetic platform offer different ways to position the laser without holding it.
Selection and Use
- Check that the room opening fits the 58–120 in. support range.
- Choose the mounting method for the surface; the pipe clamp has a 1-1/8 in. maximum diameter.
- Visible range depends on site lighting; do not treat it as guaranteed visibility in every room.
