Description
Overview
The STABILA 35712 Type 106 T Plate Level extends from 7 to 12 ft to span tall walls, doors and windows. Its reinforced two-chamber frame and keyed extension rail provide a long measuring surface, with the plumb vial positioned for convenient reading.
Features
- Two handgrips, steel hang hole and two plumb vials plus one level vial.
- Positioning scales on both sides of the extension rail.
- Removable 1-5/8 in. stand-offs for measuring around braces.
- Non-machined measuring surfaces; manufacturer lifetime vial-accuracy guarantee.
What's Included
- Type 106 T 7–12 ft plate level
- Removable stand-offs
Specifications
- Catalog number: 35712
- Length: 84–144 in. (7–12 ft)
- Normal accuracy: ±1/32 in. at 72 in.
- Reverse accuracy: ±3/64 in. at 72 in.
- Extended normal accuracy: ±1/8 in. at 120 in.
- Measuring surfaces: 2
- End caps: Standard
Applications
Use to align top and bottom wall plates or check tall door, full-height window and cabinet installations. The opposite side also provides a straightedge reference.
Selection and Use
- Use the stand-offs where timber braces interrupt direct plate contact.
- This non-magnetic model includes stand-offs; do not confuse it with the magnetic version.
- Carrying cases and replacement caps are separate accessories. Maintenance kit 33000 is available for the extension system.
