Description
Overview
The RUBI ND-7 READY 45985 is a portable countertop wet tile saw for ceramic and wall tile, with occasional porcelain-stoneware cutting. A stainless-steel table, side fence and angled guide support straight and repeat work without the footprint of a larger bridge saw.
Features
- 4.8 A motor with thermal protection.
- Folding table side supports 22.5° and 45° miter settings.
- Extruded-aluminum side fence and sliding 0–45° guide.
- Transparent splash guard keeps the cutting area visible.
- Direct-immersion blade cooling and a reinforced tubular base with non-slip feet.
What's Included
- ND-7 READY saw.
- 7 in. Premium ARROWHEAD diamond blade.
- Extruded-aluminum side stop and 45° angle guide.
- Splash guard and operator’s manual.
Specifications
- Reference: 45985
- Blade diameter: 7 in.
- Straight capacity: Up to 20 in.
- Diagonal capacity: 12 x 12 in.
- Maximum cutting thickness: 1 1/4 in.
- Motor current: 4.8 A
Downloads
Applications
Use for ceramic tile cutting where a compact, transportable wet saw is useful. The side fence supports repeated straight cuts; the angle guide and folding table provide different ways to position angled and miter work.
Selection and Use
- Check the tile’s straight or diagonal dimensions against the appropriate capacity.
- Use the water-cooling arrangement and splash guard as described in the supplied manual.
- Porcelain is an occasional-use application for this saw; select the blade and cutting method for the actual tile.
