Description
Overview
The S3 Frame Cart AT carries an S3 Slim Slab Saver frame and large-format thin material over planned jobsite routes. Four turnbuckles secure the frame, while two cargo decks can carry additional tools or material within the cartās total capacity.
Features
- 8 in. non-marking, flat-free tires.
- Adjustable wheelbase for stair setup.
- Folds for transport and storage.
What's Included
- One cart with four turnbuckles, four S3 attachment brackets and two wooden cargo decks
Specifications
- Model #: S3-FCAT-21
- Product Dimension: 59ā x 22.5ā x 14ā
- Product Weight: 62 lb
- Rated Capacity: 750 lb
- Materials: Plated steel, stainless steel, PVC plastic, 8ā closed-cell polyurethane tires (flat-free and non-marking) and wood
Downloads
Applications
Use with an S3 Slim Slab Saver frame for transporting glass panels, large tiles and gauged porcelain material. Frame compatibility requires the Kickstand Kit arrangement described in the guide.
Selection and Use
- Do not exceed 750 lb total capacity. Secure the load with the turnbuckles.
- Never ride on the cart or leave a loaded cart unattended.
- Do not tilt onto the swivel casters; follow the guide for stair wheelbase setup with the cart unloaded.
- The cart package is not an S3 reinforcement frame.
