Description
Overview
The IMER 1107548 vibrating screen fits the Mighty Small 50 hopper to screen loose, site-prepared materials before they enter the pump. It helps intercept oversized stones and debris rather than relying on the rotor/stator to pass them.
Features
- Connects to the pump’s dedicated vibrating-screen outlet.
- On/off control is provided at the machine’s control panel.
- Intended for loose materials; it is not required for bagged preblended material.
Specifications
- Part number: 1107548
- Compatible machine: Mighty Small 50
- Listed screening function: Intercepts loose debris larger than 5/16 in.
- Listed passage size: Up to 1/4 in.; this is not an increase to the pump’s allowable aggregate size
Related Information
Applications
Use the vibrating screen when preparing your own loose-material mix for the Mighty Small 50. It screens the hopper feed to help prevent oversized debris from reaching the screw and stator.
Selection and Use
- The screen does not establish the pump’s material limit: follow the lower aggregate limit specified for the exact pump model and rotor/stator setup.
- For preblended bagged material, check the material and pump instructions rather than adding screening as an automatic requirement.
